Genie Z Series User Manual

Maintenance Manual April 2018
Performance Specifications
4 S
®
Booms • Z
®
Booms Part No. 1268489GT
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function Z-34 IC Z-40N, Z-40N
RJ
Z-45/25, Z-45/25J
(DC, BE models)
Z-45/25, Z-45/25J
(IC models)
Z-45 XC
Primary boom up 15 - 21 seconds 26 - 30 seconds 32 - 40 seconds 24 - 28 seconds 26 - 30 seconds
Primary boom down 13 - 19 seconds 26 - 30 seconds 26 - 30 seconds 24 - 28 seconds 26 - 30 seconds
Primary boom extend 24 - 30 seconds 18 - 22 seconds 14 - 18 seconds 18 - 22 seconds 14 - 18 seconds
Primary boom retract 14 - 20 seconds 18 - 22 seconds 17 - 21 seconds 18 - 22 seconds 14 - 18 seconds
Secondary boom up 15 - 21 seconds 32 - 36 seconds 38 - 46 seconds 24 - 28 seconds 26 - 30 seconds
Secondary boom down 11 - 17 seconds 32 - 36 seconds 38 - 46 seconds 24 - 28 seconds 26 - 30 seconds
Jib boom up 24 - 30 seconds 16 - 20 seconds 32 - 40 seconds
(Z45J)
45 - 55 seconds 40 - 44 seconds
Jib boom down 15 - 21 seconds 16 - 20 seconds 26 - 30 seconds
(Z45J)
25 - 35 seconds 24 - 28 seconds
Jib boom rotate X 16 - 20 seconds
(Z40N RJ)
X X X
Turntable rotate 62 - 72 seconds 62 - 68 seconds 95 - 125 seconds 62 - 68 seconds 67 - 73 seconds
Platform rotate 5 - 11 seconds 10 - 14 seconds 6 - 10 seconds 6 - 10 seconds 12 - 16 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds
Function Z-51 Z-60
(DC / FE)
Z-62
(includes TRAX
models)
Z-80
Primary boom up 36 - 40 seconds 60 - 70 seconds 60 - 65 seconds 60 - 70 seconds
(retracted)
80 - 96 seconds
(extended)
Primary boom down 36 - 40 seconds 60 - 70 seconds 65 - 70 seconds 75 - 85 seconds
(retracted)
80 - 96 seconds
(extended)
Primary boom extend 18 - 22 seconds 41 - 49 seconds 40 - 50 seconds 48 - 52 seconds
Primary boom retract 18 - 22 seconds 31 - 39 seconds 45 - 50 seconds 38 - 52 seconds
Secondary boom up 36 - 40 seconds 31 - 39 seconds 40 - 45 seconds 38 - 48 seconds
Secondary boom down 36 - 40 seconds 31 - 39 seconds 45 - 50 seconds 38 - 48 seconds
Jib boom up 45 - 55 seconds 13 - 17 seconds 68 -
73 seconds
23 - 33 seconds
Jib boom down 25 - 35 seconds 13 - 17 seconds 77 - 82 seconds 21 - 31 seconds
Turntable rotate 82 - 88 seconds 39 - 43 seconds
(stowed)
62 - 83 seconds
(extended)
120 - 125 seconds
(stowed)
240 - 245 seconds
(extended)
114 - 126 seconds
(retracted)
200 - 240 seconds
(extended)
Platform rotate 6 - 10 seconds 10 - 14 seconds 12 - 17 seconds 10 - 14 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
