Genie Z Series User Manual

April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S
®
Booms • Z
®
Booms 5
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function Z-135 ZX-135
Primary boom up/down 88 - 105 seconds 110 - 125 seconds
Primary boom extend/retract 38 - 42 seconds 35 - 48 seconds
Secondary boom up/down 80 - 95 seconds 80 - 95 seconds
Secondary boom extend/retract 88 - 98 seconds 88 - 98 seconds
Jib boom up/down 38 - 43 seconds 38 - 43 seconds
Jib boom extend/retract 27 - 38 seconds 27 - 38 seconds
Turntable rotate stowed 88 - 92 seconds 88 - 92 seconds
Turntable rotate
(jib or primary boom extended)
160 - 180 seconds 160 - 180 seconds
Turntable rotate
(jib and primary boom extended)
280 - 350 seconds 280 - 350 seconds
Platform rotate 20 - 25 seconds 20 - 25 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds

Genie Z Series Specifications

General

Lift Capacity	500 lb (227 kg) to 660 lb (300 kg)
Gradeability	30%
Power Source	Diesel, Electric
Capacity	500 lb (227 kg) to 1, 000 lb (454 kg)
Drive System	4-wheel drive
Tire Type	Solid
Steering	2-wheel or 4-wheel
