Maintenance Manual April 2018

Performance Specifications

6 S

Booms • Z

Booms Part No. 1268489GT

Note: Function speeds are maximum from platform controls with maximum rated load in platform.

Function SX-105 XC SX-125 XC SX-135 XC

Primary boom

up/down, (stowed)

80 - 88 seconds / 83°

88 - 94 seconds / 75°

Primary boom up/down

100 - 110 seconds / 83°

string pot = 120 in / 305cm

100 - 110 seconds / 83°

string pot = 120 in / 305cm

26 - 29 seconds / 10°

string pot = 138 in / 351cm

Primary boom up/down

33 - 38 seconds / 20°

string pot = 225 in / 571cm

33 - 38 seconds / 20°

string pot = 220 in / 559cm

24 - 27 seconds / 10°

string pot = 202 in / 513cm

Primary boom up/down

40 - 45 seconds / 20°

string pot = 285 in / 724cm

40 - 45 seconds / 20°

string pot = 300 in / 762cm

34 - 37 seconds / 10°

string pot = 268 in / 681cm

Primary boom up/down

18 - 23 seconds / 5°

string pot = 345 in / 876cm

18 - 23 seconds / 5°

string pot = 345 in / 876cm

21 - 24 seconds / 5°

string pot = 357 in / 907cm

Primary boom up/down

X 25 - 30 seconds / 5°

string pot= 582 in / 1478cm

Primary boom extend 120 - 140 seconds

170 - 190 seconds

30 - 33 seconds

0 - 100 in / 254cm

Primary boom retract 120 - 140 seconds

170 - 190 seconds

30 - 33 seconds

100 in / 254cm - 0

Jib boom up/down 28 - 32 seconds

28 - 32 seconds

60 - 65 seconds

(retracted)

122 - 130 seconds

(extended)

Jib boom

extend/retract

X X 50 - 60 seconds

Jib boom rotate X X X

Turntable rotate,

(stowed)

170 - 190 seconds

17 - 23 seconds
