April 2018 Maintenance Manual
Performance Specifications
Part No. 1268489GT S
®
Booms • Z
®
Booms 7
Note: Function speeds are maximum from platform controls with maximum rated load in platform.
Function SX-150 SX-180
Primary boom
up/down, (stowed)
80 - 88 seconds / 82° 80 - 88 seconds / 82°
Primary boom up/down 100 - 110 seconds / 82°
string pot = 76 in / 193cm
100 - 110 seconds / 82°
string pot = 76 in / 193cm
Primary boom up/down 45 - 50 seconds / 20°
string pot = 158 in / 401cm
45 - 50 seconds / 20°
string pot = 158 in / 401cm
Primary boom up/down 71 - 80 seconds / 20°
string pot = 238 in / 605cm
71 - 80 seconds / 20°
string pot = 238 in / 605cm
Primary boom up/down 26 - 31 seconds / 5°
string pot = 370 in / 940cm
26 - 31 seconds / 5°
string pot = 370 in / 940cm
Primary boom up/down X 34 39 seconds / 5°
string pot = 596 in / 1514cm
Primary boom extend
0 - 100 in / 254cm
30 - 33 seconds 30 - 33 seconds
Primary boom retract
100 in / 254cm - 0
30 - 33 seconds 30 - 33 seconds
Jib boom up/down 58 - 62 seconds 58 - 62 seconds
Jib boom rotate 28 - 32 seconds 28 - 32 seconds
Turntable rotate
(stowed)
38 - 42 seconds
drive enable to drive enable
38 - 42 seconds
drive enable to drive enable
Turntable rotate 63 - 70 seconds
drive enable to drive enable, 80°
string pot = 36 in / 91.4cm
63 - 70 seconds
drive enable to drive enable, 80°
string pot = 36 in / 91.4
Turntable rotate 109 - 120 seconds
drive enable to drive enable, 80°
string pot = 76 in / 193cm
(above 75 ft / 22.8m)
109 - 120 seconds
drive enable to drive enable, 80°
string pot = 75 ft / 22.8m
(above 75 ft / 22.8m)
Turntable rotate 155 - 175 seconds
drive enable to drive enable, 80°
string pot = 258 in / 655cm
(above 125 ft / 38.1m)
155 - 175 seconds
drive enable to drive enable, 80°
string pot = 258 in / 655cm
(above 125 ft / 38.1m)
Platform rotate 20 - 24 seconds 20 - 24 seconds
Platform level
(10° range of motion)
ANSI/CSA
AS/CE
3 - 5 seconds
20 - 22 seconds
