796688 (4188-657)_i2 _06/03
65
Any service and maintenance work on the panel or system must be carried out by a
trained maintenance engineer from the fire alarm servicing organisation.
Message displayed Description and checks
Day mode entered
The day mode is active. The day mode is automatically exited
after a pre-configured timeout period has elapsed
Detection devices
config. OK
The detection device assignment has been configured
correctly.
Detection devices
not zoned
The fire detection devices on the loop are not assigned to
zones. Assign each fire detection device to a zone of the fire
panel.
Device disabled /
enabled
The device has been manually disabled / enabled.
Device has no
address
A new device has been wired on the loop whilst the loop was
running.
Device isloating
short circuit
The wiring between the displayed devices has a short circuit. If
however the short was on the wiring between the panel and
device then only one device address is displayed.
Device type
compatible
The device found on the loop is a valid type.
Device type OK
The device type replaced is now OK.
Device wrong type
The device replaced is of a different type. Replace like for like
device.
Duplicate address
fault cleared
The duplicate addressing fault has cleared.
Duplicate address
occurred
The panel has found two devices having the same address.
Check the wiring and re-allocate the loop by re-powering the
loop and detection.
Engineering mode
entered
The engineering mode has been entered to allow access to
menu options under level-4.
Exit engineering
mode
There panel has timed out of engineering mode (level 4).
Exit to level one
There has been a manual exit to access level 1 from either
level 2,3 or 4.
External evacuate
activated
The external evacuate (local input) is still active.
External evacuate
fault cleared
The external evacuation (local input) has been cleared.
External evacuate
operated
There has been an external evacuate signal at the local input
and the system alarms are sounding.
External evacuate
reset
The external evacuate signal has been reset for normal
operation.
Fault routing
disabled
The fault routing equipment is disabled.
Fault routing
enabled
The output signal to fault routing equipment is enabled.
Fault routing
output fault
cleared
The fault associated with the fault routing output has cleared.
Fault routing
output O/C or SC
There is a open or short circuit fault between the fire routing
equipment and the control panel. Check the wiring between
the fault routing equipment and fire panel.
Fire input into
test
The local fire input has been manually put into test state.
Fire input
operated
The local input has signalled a fire condition.
Fire input reset
The local fire input has been reset for normal operation.
