Fixed IP Dome

4. Connect the network, power and other cables to the camera. See

16.5 Connecting the Camera.

5. Access the live view. See 19.1 Accessing the Live View.

6. Based on the live view, adjust the camera to a desired angle as

illustrated below.

Tip: The 3-axis mechanism offers flexible and easy ceiling / wall

installation.

Pan Adjustment

Figure 16-6

Tilt Adjustment

Figure 16-7

241
