Rotational Adjustment

Figure 16-8

7. Adjust image clarity using the GV-IP Device Utility program. For

details, see 19.2 Adjusting Image Clarity.

8. Secure the housing cover as shown in step 2. Remove the indicated

part when necessary.

Figure 16-9

Note: Adjust the black mask inside the housing cover to make sure the

camera view is not obscured.

242
