88
9.4 Connecting the Camera
Power Connection
Use one of the following methods to supply power to the camera. Note that
GV-BL2511-E / 5311-E do not support PoE.
ď‚· Use a Power over Ethernet (PoE) adapter to connect the camera to the
network, and the power will be provided at the same time.
ď‚· Plug the power adaptor to the terminal block as shown below. For all
models (except GV-BL2511-E / 5311-E), insert the striped wire to the
left pin (+); for GV-BL2511-E / 5311-E, insert the striped wire to the right
pin (-).
All Models except GV-BL2511-E / 5311-E
GV-BL2511-E / 5311-E
To Next Page
