GeoVision GV-IPCamera Series User Manual

Target Bullet Camera (Part I)
119
12
12.4 Connecting the Camera
12.4.1 Wire Definition
The data cable provides connections for power, ground and network access.
The wires are defined below:
No. Wire Color Definition
1 Red DC 12V
2 Black Ground
3 Black (thick) PoE, Ethernet
