Mini Fixed & Rugged Dome
47
5
Refer to the wire definition and illustrations below to connect the power and
network.
5.4.1 Wire Definition
GV-MDR Series
Power and network connectivity is provided through a PoE cable.
Wire Color Definition
Gray PoE, Ethernet
5.4.2 Power and Network Connection
Use one of the following methods to power on and connect your camera to
network:
ď‚·
Wired connection with PoE: Use a Power over Ethernet (PoE)
adapter to connect the camera to the network, and the power will be
provided at the same time.
ď‚·
Wired connection with network cable (GV-MFD Series only):
Connect the camera with a standard network cable and use the power
adapter to supply power. See Powering On the Camera below to
assemble the terminal block with power adapter.
ď‚·
Wireless connection (GV-MFD1501 Series / 2401 Series / 2501
Series / 3401 Series / 5301 Series only):
Connect the camera with a
GV-WiFi Adapter (optional accessory) and use the power adapter to
supply power.
