GeoVision GV-IPCamera Series User Manual

Ultra Bullet Camera
109
11
3. Slide the components through the Ethernet cable as shown below.
1
2
3
4
5
A
4. Paste the item 1 sticker to item 2.
5. Move all the components toward the LAN connector, fit item 4 to item 2,
secure item 3 to the LAN connector (Item A) and finally secure item 5
to item 2 tightly.
IMPORTANT: Item 5 must be secured tightly to waterproof the
LAN connector.
6. Prepare an RJ-45 connector, reconnect the RJ-45 connector to the
cable, and then connect the camera to network.
