4
No. Name Description
7 Power LED
Indicates the power is supplied. For detail, see
the table below.
8
Auto Iris
Connector
Plug the iris control cable to the connector.
9 DC 12V Port Connects to power.
10 LAN / PoE Connects to a 10/100 Ethernet or PoE.
11 Default
Resets the camera to default settings. See 27.
Restoring to Default Settings later in the Quick
Start Guide.
12 Iris Screw Adjusts the iris of the camera.
13 Zoom Screw Adjusts the zoom of the camera.
14 Microphone Records the sounds.
15 Focus Screw Adjusts the focus of the camera.
16 Status LED
Turns on when the unit is ready for use. For
detail, see the table below.
LED Description
Power LED turns green The system powers on and succeeds to boot up.
Status LED turns green The system is ready for use.
