GeoVision GV-IPCamera Series User Manual

44
6. Install the cable connector to waterproof the cable. You should have 5
parts:
1 2 3 4
5
A. Prepare an Ethernet cable with the RJ-45 connector on one end
only.
B. Connect the Ethernet cable to the camera cable.
C. Paste the sticker to the camera cable and slide in all the
components as shown below.
D. Move all the components toward the RJ-45 connector, fit item 4 to
item 2, secure item 3 to the camera cable and finally secure item
5 to item 2 tightly.
