Gerber EDGE FX - Menu Tree - Diagnostic Menu

96
GERBER EDGE FX
Menu Tree
Menu Tree – Diagnostic Menu
SYSTEM MENU
F1 NETWORK CANCEL F3
F2 DIAG MOTION F4
DIAGNOSTIC MENU
F1 TEST PRINT CANCEL F3
F2 NETWORK VERSION F4
Starting
Network Test
Press F1, to start
the Test Print
Canceling Job
Please stand by…
NETWORK TEST MENU
F1 CANCEL F3
F2 Quality: None F4
Rate: 0 Kbyte/sec
EDGE FX VERSION
F1 Release: CANCEL F3
F2 XX.XX NEXT F4
1 of 9
NEXT scrolls through
EDGE FX VERSION
menus 1 through 9:
Release
Application
BootStrap
BootLoader
Language
FPGA
History
Fire File
RFID
Returns to the
MAIN MENU
MAIN MENU
F1 PAUSED CANCEL F3
F2 Mode: Single F4
Job: TEST PRINT
CANCEL JOB
F1 YES NO F3
F2 F4
Quality results
can be:
EXCELLENT
GOOD
POOR
NONE
