45
SYSTEM MENU
F1 NETWORK CANCEL F3
F2 DIAG MOTION F4
2 Press F4, MOTION to open the MOTION MENU.
MOTION MENU
F1 FOIL CANCEL F3
F2 HOME F4
3 Press and hold F1, FOIL to advance the foil from the supply roll to the take-up roll to
expose a new section of the foil.
4 Press F3, CANCEL to return to the MAIN MENU.
Pausing and restarting a job
Pressing F1, ONLINE while the job is printing pauses the job. When the job is paused you can
slew the material. Press F1, ONLINE again when a job is paused to restart the job at the same
location at which printing stopped.
Tip: To ensure correct registration when printing is paused and resumed, the GERBER EDGE
FX is set to overlap the foil at the position where the job was interrupted. The default amount
of overlap is 15 pixels. You may adjust the overlap to between 5 and 25 pixels. See “Changing
the overlap setting” on page 51.
Canceling a job
From the MAIN MENU, press F3, CANCEL on the control panel to stop the job and clear it
from the printer.
MAIN MENU
F1 ONLINE CANCEL F3
F2 Mode: Single SYSYEM F4
The GERBER EDGE FX displays a confirmation menu. Press F1, YES to cancel the job, or F3, NO
to return to the previous menu.
CANCEL JOB?
F1 YES NO F3
F2 F4
