Gerber EDGE FX User Manual

47
Chapter 6:
Configuring the GERBER EDGE FX via the Web
Interface
The GERBER EDGE FX has a web interface that allows you access to the printer via a web
browser on any computer connected to it via a network or through direct connection. The web
interface address is the same as the GERBER EDGE FX IP address, for example:
http:// 169.254.128.129.
Note: When the GERBER EDGE FX ships from the factory, the default IP address is
169.254.128.129. The IP address may change during installation (and is different for each
printer when there are multiple printers at one location). To access the web interface, use the
current IP address assigned to that printer.
Through the web interface you can perform the following functions without using the GERBER
EDGE FX control panel:
♦ Check job status
♦ Change system settings such as overlap, language, or printer name
♦ Enter or change network addresses of the printer
♦ Perform system diagnostics
♦ Perform a firmware update
♦ View Gerber contact information
Tip: You may find it helpful to create a shortcut to the GERBER EDGE FX web interface on
your computer's desktop for quick access.

Gerber EDGE FX Specifications

General

Print Technology	Thermal transfer
Resolution	300 dpi
Connectivity	Parallel
Media Types	Vinyl, Reflective
Max Media Width	15 in (381 mm)
Max Print Width	11.8 in (300 mm)
