41
9 Carefully close the GERBER EDGE FX cover. Do not to slam the cover shut.
CAUTION: Slamming the cover shut can cause damage to the print head. Always
close the cover carefully.
10 On the MATERIAL MENU press F1, OK to confirm that the correct material is loaded.
MATERIAL MENU
F1 OK CANCEL F3
F2 SUBSTITUTE MOTION F4
Need: 220
11 The FOIL MENU requests the first foil needed for the job. See “Loading a foil cartridge
into the GERBER EDGE FX” on page 42 for additional instructions.
Substituting a different material
It is very important to use the material that has been designated for that job. Each material has
specific print settings assigned that ensure good foil adhesion. Failure to use the correct
material will result in incorrect print settings for the material actually being used.
You can choose a different material when designing the job in OMEGA, before outputting the
job in GSPPlot, or at the GERBER EDGE FX before printing begins. See the OMEGA Reference
Manual or Help for instructions on substituting materials in OMEGA or GSPPlot.
To substitute a material at the GERBER EDGE FX
1 After receiving a job the GERBER EDGE FX displays MATERIAL MENU. The material
designated for the job displays on the bottom line of the menu.
MATERIAL MENU
F1 OK CANCEL F3
F2 SUBSTITUTE MOTION F4
Need: 225
2 Press F2, SUBSTITUTE to choose a different material and display the MATERIAL
SUBST. MENU.
MATERIAL SUBST. MENU
F1 OK CANCEL F3
F2 PREV NEXT F4
Subst: [1] 220
3 Press the F2, PREV or F4, NEXT (or the left and right slew keys) to scroll through the
list of available material. The substrates are numbered as shown in brackets [1].
4 When the desired material displays, press F2, OK to confirm the material selection. A
confirmation message displays.
