Trial run
09 / 680
First trial run
Corn header to lower near to the
ground. Keep off the dangerous zone.
All guards to close!
Machine first to let idle.
Check the smoothness of running.
In case of trouble turn off immediately!
Secure against unwanted lowering!
Troubleshoot!
Check the working speed on the monitor.
(n =720-750 r/min)
Reversing
ll modern combines are fitted with a standard reversing
device for the header drive.
This device for allowing the machine to reverse can be
used for cleaning during the operation of the header
without any limitation.
• Function to check
Test of the heeling compensation
Prior to start-up, the pivoting shield function of the combine
is to be checked combined with the corn header.
• PTO-shaft length and sufficient overlapping to
check!
• Slope steering to check
(optional)
Keep off the dangerous zone whilst
the machine is running !
