Changes on the CNH combine gathering channel
Before mounting a header to the CNH-combine of the
series CX and CR it is a must to remove the brackets (L) of
the upper arm location.
Attention !
Only the brackets to remove, since the other mechanism
forms the swivel of the pivoting shield!
Channel view: Brackets removed
Flat steel with screws (S) must be left on the machine.
Holder for upper arm location
To allow for a later use of the upper arm location, an
additional part no. 550900 is supplied along with the
machine.
This additional part is screwed on the existing bracket with
longer screws (M16 x 50).
Do not weld in the area of the bore
Holder for u
er arm location
