5. You will then be asked if you want to assign the PAB-devices now, click YES.
6. Reconnect to the ProfiLux 4 and go back to the SYSTEM settings page. Clicking on the
(+) next to PAB will show the newly added PAB-device.
NOTE
If this is your FIRST Powerbar5.1 or FIRST GHL Doser 2.1 Slave, the socket
and pump numbering is automatically assigned. The first PB5.1 is assigned to
Sockets 1-5 and first D2.1 is assigned to Dosing Channels 1-4.

GHL ProfiLux 4 Specifications

General

Model	ProfiLux 4
Category	Controller
Power Supply	12V DC
pH Ports	2
Redox Ports	1
Conductivity Ports	1
Level Ports	4
Digital Inputs	4
12V Outputs	4
Real-time clock	Yes, with battery backup
Digital Outputs	4
Expandable	Yes
Connectivity	USB, Wi-Fi, LAN
Display	Graphic LCD display
Expansion Slots	4
Processor	32-bit
Channels	16
Operating Temperature	0°C to 50°C
