ProfiLux 4 Resource Guide

EN 2018-13-11 67

2. Select SWITCH CHANNELS AND OUTLETS.

3. Select the outlet that has or will have the light fixture connected to it.

4. Set the function to ILLUMINATION and select the channel number that has your

illumination settings.

 For example, if you created the function on Illumination channel 1, set the

function to ILLUMINATION 1. If Illumination channel 2 was used – set the

function to ILLUMINATION 2, etc.

5. Type-in a description in both fields, set a black-out delay if necessary, and then click OK.

6. Click SAVE CHANGES.

TIP: Color code your Illumination channels

If you’d like to give each Illumination channel a specific color, you can do so

by simply selected the desired Illumination channel and clicking the drop-

down box.
