ProfiLux 4 Resource Guide
EN 2018-13-11 91
TIP: Use your ATO sensor also as an AWC sensor
If you’re already using a sensor for a single-sensor ATO function, you can
double-up this sensor and also use it for your AWC max-point. To do this,
simply follow the steps below and use the existing Control Circuit number
where you created the ATO function. This Control circuit should then be set
to ATO & WATER CHANGE.
You can view our “AWC setup for ProfiLux 4“ how-to video by clicking the
link below.
Auto Water Change setup:
https://youtu.be/U1oUUz-7FJI
To setup AWC control, please follow these steps:
CONNECT ALL ACCESSORIES
1. Connect the 2x GHL Float or Optical sensors to an available Level-port on your P4.
Take note which color port on the P4 you are connecting the sensors to.
i. Purple port: Level 1/2
ii. Green port: Level 3/4
If you are connecting the sensors to an expansion card or Expansion Box 2, the
Level-port numbering will continue beyond Level 3/4.
i. For example, if you have a PLM-4Level expansion card, the Level
numbering would be 5/6 for one port and 7/8 for the second port.
ii. If you do not have any Level-port expansion cards on the P4 and instead
have an Expansion Box 2, Level 1/2 on the EXB2 would actually be Level
5/6.
If a single sensor is connected directly to a Level-port, the Level sensor will be
assigned to the first number of that Level-port.
i. For example, if a single sensor is connected to Level 1/2, the sensor
would automatically be assigned as Level sensor #1.
CREATING THE FUNCTION
1. Click on the (+) icon to the left of
Probe/sensor controls
and select LEVEL.
2. Select an unused CONTROL CIRCUIT
3. Select the desired
Operation mode.
Water change: Select this option if you want to assign dedicated sensors to
this function.
To Next Page
