ProfiLux 4 Resource Guide
EN 2018-13-11 92
ATO & Water change: Similar to Water change, but also includes the ATO
function where the top (max-point) sensor will serve for both ATO and AWC
functions.
i. If this option is selected, select if you want the ATO function always
active.
4. Set the Maximum on-time.
This is a failsafe feature that will turn OFF the assigned Powerbar outlets in case
a level sensor does not respond.
5. If you wish to have the alarm for this function automatically reset when normal
operation is detected, check the box.
If the box is left unchecked and an alarm is triggered by this function, ProfiLux
will keep the assigned Powerbar outlets OFF until you manually reset the error.
6. Select the TIMER number which will be responsible for activating this AWC function.
Select a TIMER number that is not currently being used. You will go to this
TIMER function and configure it shortly.
7. Select the sensor numbers that will be used for this function.
For example, if you have a single sensor connected to the Level 1/2 port, select
1.
If you are using a splitter cable and have both sensors connected to Level port
1/2, select 1 and 2. Same rules apply for if these sensors are connected to Level
port 3/4, 5/6, etc.
8. Type-in a description for this AWC function and click OK.
ASSIGNING AWC FUNCTION TO A SPECIFIC TIMER
