GMP PROTOPIC AUTO-540 HS - Control Panel Operations; Understanding Display Items

HOW TO USE CONTROL PANEL
② "TOP:113℃ 123℃-W" - for display of Temp. & Jobs
To display Setting / Current Temp. of Laminating Roller and Job Availability. Setting Temp. Range is "0~150℃".
- "W"(WAIT) : means "not ready for lamination" (temp. is too low or too high for lamination).
- "R"(READY) : means "ready for lamination".
NOTE : Refer to "Buttons" functionality for how to set temp.
③ "BURST" - for display of substrate cutting size
To display operation time for bursting roller. Setting Bursting Point Range is Min. "580"~ Max. "660".
Recommendable Setting Value is 610~620.
NOTE : Refer to "Buttons" functionality for how to set bursting time.
④ "LENGTH" - for display of substrate length
Displayed value means substrate length. Setting value of substrate length is a required length for lamination.
Setting substrate length range is 250~800mm.
NOTE : Refer to "Buttons" functionality for how to set substrate length.
⑤ "SPEED" - for display of roller speed
To display rotation speed of laminating roller. Speed setting range is Min. "1" ~ Max. "15".
NOTE : Start at low speed for initial stage of job.
⑥ "FWD-S OFF" - for display of status for LAMINATOR MAIN MOTOR.
- FWD-S : Forward Operation is stopped.
- REV-R : Reverse Operation is being processed.
- FWD-R : Forward Operation is being processed.
- JOG : In JOG status
- REV-S : Reverse Operation is stopped.
⑦ "C:00055" - for display of daily lamination q'ty
To display q'ty of laminated results for a certain period. It can be reset if it is required.
NOTE : Refer to "Button" functionality for how to reset counter.
