27
FAN1~FAN9
6 P in fan connector (total 9 pcs)
J40~J47
4 P in fan connector (total 8 pcs)
SATA1/SATA2
SATA DOM CONN (SATA 7 Pin) (with PWR design)
J37/J38
SATA DOM PWR CONN
J64
Chassis Intrusion Header, Chassis Intrusion Detection
J24/J25
Slimline PCIe X 8 CONN (defined by SFF-9402
standard)
B1
Buzzer
DIMMA0-DIMMH0
DIMMA1-DIMMH1
CPU0 DIMM , 16 Slots
DIMMA3-DIMM
H3
DIMMA4-DIMM
H4
CPU1 DIMM, 16 Slots
SW3
Rear BMC Reset Button
COM1
Rear COM Port
J4
Rear BMC IPMI LAN Port
J2
1X2 Gigabit data network port
CN1
Rear VGA Connector
SW2
Rear UID Button (Blue LED)
SW1
Rear Power Button
J51/J53/J56/J58
2X4 Front BP HDD Power Connectors (White)
J59/J61
2X4 Risers and GPU Card Power Connectors (Black)
J52/J54/J55
2X2 Rear BP HDD Power Connectors (Black)
J60
2X3 Riser 4 Power Connector (Black)
J69
PEHP CPU0 (1.8V CPU I2C Reserved for U.2 HDD
backplane)
J70
PEHP CPU1 (1.8V CPU I2C Reserved for U.2 HDD
backplane)
J49/J50
CRPS Slots
SW4
SKU IDs ( Reserved )
J7/J8/J9/J10
BP1~BP4 BMC I2C Connector (Reserved for HDD BP
backplane )
J57
1X2 CD/DVD Power Connector
J63
NVME Key(VROC)
J13
VR Debug Mode Jump (Reserved for RD test Only)
No Jumper
J14
CPLD No CPU Power ON Jump (Reserved for RD test
Only)
No Jumper
J30
2X4 SATA sGPIO Header (for 8643 miniSAS HD Conn
J29/J31)
J28
2X4 sSATA sGPIO Header (for 8643 miniSAS HD Conn
J28)
J33
BMC Watch Dog Timer Enable (Reserved for RD test
Only)
J5
IPMB Connector
J67
SCY Strap , (2/3)High = Disable Flash Descriptor
Security
Default
(1/2)Low
J11
PCH_HOST I2C Header (Reserved for RD test Only)
