INTRODUCTION RT9130E SERVICE MANUAL
1-4 Published 08-25-09, Control # 077-04
Table 1-1
Axle Weight Distribution Table
Description
CG to CL Bogie
cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Basic Unit
Maximum Axle Loads Allowed 40824 (90000) 40824 (90000)
Maximum Tire Loads Allowed 40824 (90000) 40824 (90000)
Carrier 4 x 4; All Fluids 212.1 (83.50) 24132 (53202) 10360 (22840) 13772 (30362)
Front Outrigger Box and Beam Assembly 675.6 (266.00) 4276 (9427) 5848 (12892) -1572 (-3465)
Rear Outrigger Box and Beam Assembly -208.3 (-82.00) 4276 (9427) -1803 (-3974) 6079 (13401)
Superstructure w/cab plus w/main hoist plus
950 ft cable; less counterweight plus lower
lift pin
108.4 (42.69) 6707 (14786) 1472 (3245) 5235 (11541)
Removable Counterweight (includes
cylinders, aux hoist and cables)
-143.4 (-56.47) 12739 (28084) -3698 (-8154) 16437 (-36238)
Boom Assembly; w/LMI, 2/7 Nose Sheaves,
Pivot Pins
661.8 (260.55) 15187 (33482) 20345 (44852) -5158 (-11370)
Lift Cylinder 542.3 (213.50) 1769 (3900) 1942 (4281) -173 (-381)
Complete Basic Machine
4 x 4 chassis; Cummins QSC8.3 300 Tier 3
engine w/ transmission; front and rear axles;
33.25 x 29 tires; main hoist
w/289 m (950 ft) of 3/4 in. cable; full fuel and
hydraulic oil; LMI; plus all the above.
246.5 (97.03) 69086 (152308) 34466 (75983) 34620 (76325)
Add To Basic Unit Weight
10.97 to 17.98 m (36 to 59 ft)
Bi-Fold Boom Extension
749.9 (295.25) 1411 (3110) 2141 (4721) -730 (-1611)
10.97 meter (36 ft) Fixed Boom Extension 837.1 (329.56) 1043 (2300) 1768 (3897) -725 (-1597)
10.97 to 17.98 m (36 to 59 ft) Bi-Fold
Hydraulic Boom Extension
805.2 (317.00) 1595 (3516) 2599 (5730) -1004 (-2214)
10.97m (36 ft) Fixed Hydraulic Boom
Extension
893.6 (351.83) 1235 (2722) 2234 (4924) -999 (-2202)
Components for Hydraulic Boom Extension 936.4 (368.65) 92 (202) 174 (383) -82 (-181)
Boom Ext. Carrier Brackets (Bolt On) 606.1 (238.62) 100 (220) 122 (270) -22 (-50)
Auxiliary Boom Nose - Installed 1346.2 (530.00) 57 (125) 155 (341) -98 (-216)
72 mt (80 Ton), 7 Sheave Hookblock -
Stowed in trough
469.9 (185.00) 726 (1600) 690 (1522) 36 (78)
118 mt (130 Ton), 8 Sheave Hookblock -
Stowed in trough
469.9 (185.00) 1147 (2530) 1091 (2406) 56 (124)
9.0 mt (10 Ton), Headache Ball (Swivel)-
Attached to O/R Box
787.4 (310.00) 308 (680) 491 (1084) -183 (-404)
Driver 233.7 (92.00) 113 (250) 53 (118) 60 (132)
Rear Mounted Pintle Hook -212 (-83.50) 14 (30) -6 (-13) 20 (43)
Boom Removal Kit 601.0 (236.66) 39 (85) 47 (103) -8 (-18)
