Grove RT9130E - Page 17

Published 08-25-09, Control # 077-04 1-5
RT9130E SERVICE MANUAL INTRODUCTION
1
GROVE
Delete: Counterweight (24,000 pounds) -142.5 (-56.10) -10886 (-24000) 3140 (6922)
-14026
(-30922)
Delete: Auxiliary Hoist Cable (700 ft) -159.4 (-62.76) -397 (-875) 128 (282) -525 (-1157)
Delete: Air Conditioning -54.3 (-21.37) -93 (-205) 10 (23) -103 (-228)
Delete: General 33.25 X 29 (38) Tires (for
travel)
247.0 (97.25) -4318 (-9520) -2159 (-4760) -2159 (-4760)
Heavy Counterweight Package (16000 lb) -137.2 (-54.03) 7258 (16000) -2016 (-4445) 9274 (20445)
Lift Cylinder Travel Support 570.9 (224.75) 57 (125) 65 (144) -8 (-19)
Counterweight Stand (pinned to carrier) 616.6 (242.74) 78 (172) 97 (214) -19 (-43)
26 ft Boom Extension Insert w/LMI 652 (1437)
Tire Removal Tool 247 (545)
Description
CG to CL Bogie
cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
