7-10 Published 08-25-09, Control # 077-04
POWER TRAIN RT9130E SERVICE MANUAL
FRONT
6689-3
FIGURE 7-3 continued
18
19
20
21
22
23
Item Description
18 Radiator Assembly
19 Fuel Filter/Water Separator
20 Water In Fuel Sensor
Item Description
21 Engine
22 Fuel Injector Pump
23 Electric Lift Pump
