General Operation: Sequestration 111
Haemonetics
®
Cell Saver
®
Elite
®
+ User Manual P/N 130859-US, Manual Revision: AA
Figure 56, Blood bag adaptor harness
Inspecting the
Installation
Always inspect the disposable components after completing the installation.
1. Inspect all parts of the disposable components and verify that there are
no twists, kinks, or flat spots.
2. Verify that all connections are secure and all appropriate clamps are
closed.
3. Close the device cover, ensuring that no tubing is inadvertently clamped
off.
1. Effluent line connection
2. White, blue and yellow
ratchet clamps
3. Green ratchet clamps
4. Collection bags
5. Air bag
