Introduction 21
Haemonetics
®
Cell Saver
®
Elite
®
+ User Manual P/N 130859-US, Manual Revision: AA
Note: The device should not be used near active high-frequency surgical
equipment or in the RF shielded room of MRI equipment, where the intensity
of electromagnetic disturbances is high.
Electrical
Specifications
The electrical specifications for operating the Cell Saver Elite+ device are as
follows.
Attention: The Cell Saver Elite+ device meets the requirements of the IEC/EN
60601-1-2 Standard, Electromagnetic compatibility (EMC).
Additional IEC/EN compliance information is available in Appendix A.
Note: The power source used must be properly grounded.
*In accordance with IEC/EN 60601-1standard, medical electrical equipment, general
requirements for safety.
Table 9, Environmental Specifications
Conditions Values
Ambient operating temperature 10 °C to 27 °C (50 °F to 80.6 °F)
Storage/transportation
temperature
-20 °C to 50 °C (-4 °F to 122 °F)
Operating humidity level 8 to 80% R.H., non-condensing above 0°C
Atmospheric pressure range <
2438 meters (8000 ft.)
Pollution degree Pollution degree 2
Table 10, Electrical Input Power
Rated Voltage Rated Current Fuse Frequency
100–120 V 3.0 A T3.15A 250V 50/60 Hz
200–240 V 1.5 A T3.15A 250V 50/60 Hz
Table 11, Enclosure/Chassis Leakage Current Specifications*
Condition Polarity Ground Max Value
Normal Normal Normal 100 µΑ
Reverse Normal 100 µΑ
Single Fault Reverse Open 500 µΑ
Normal Open 500 µΑ

Haemonetics Cell Saver Elite+ Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
User Interface	Touchscreen display
Automated Processing	Yes
Relative Humidity	20% to 80%, non-condensing
Data Management	Data logging and reporting
Anticoagulant	Citrate
Wash Volume	Adjustable
Bowl Size	125 mL, 225 mL
Processing Time	Typically 3-5 minutes per cycle
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Category	Intraoperative Blood Recovery System
