Note: As a safety feature, the barcode reader emits a low-level laser until it
detects a barcode. It then turns on a full-power laser to scan the barcode. The
reader recognizes Codabar, Code 128, and ISBT 128 formats as valid barcode
formats.
Stop Key Pressing the (Stop) key stops the pump and centrifuge. The status
indicator shows that the device is stopped. To restart the current phase, ensure
the device cover is closed; then touch (Play). To start a different phase,
touch the corresponding phase pad.
When the device is stopped in the Prime or Fill phase, double-pressing the
Stop key puts the device into Standby mode.
Touch Screen
Mount
The touch screen mount allows the user to move the touch screen horizontally
around the IV pole and adjust the angle of the screen.
USB
Connection
The USB connection is used for software upgrades and allows authorized
users to download procedure and technical data to a portable USB flash drive.
Attention: Do not connect non-approved devices (such as cellular phones,
etc.) to the USB ports. Approved devices must comply with IEC/EN 60601-1 or
IEC/EN 60950-1.
Ethernet
Connection
The Ethernet connection enables the device to communicate with the
designated server application (if equipped) in the absence of a wireless
network connection.
