43 7.1 channel unbalanced inputs
Accept audio outputs from any multi-
channel analog source (such as DVD,
SACD, and DVD audio player).
May be used with stereo, mono, 5.1
channel or 7.1 channel sources.
44 7.1 channel unbalanced outputs
Connect to the LINE inputs of audio
power amplifiers. The SUB output is
normally fed to the low-level LINE input of
an active subwoofer, or may feed a
passive subwoofer and a separate power
amplifier.
45 Auxiliary channel outputs
Connect to the LINE inputs of power
amplifiers and subwoofers.
Special Output 1 is Aux channel 9 (top)
and Aux Channel 10 (bottom). Special
Output 2 includes two additional
subwoofer line outputs.
46 Power inlet and main switch
