HQ Pro-Stitcher User Manual07/23/123.2 Installation Instructions
GROUNDED OUTLET BOXES
METAL
SCREW
ADAPTER
(B)
(C)
TAB FOR
GROUNDING
SCREW
(A)
GROUNDING PIN
is product is for use on a nominal 120 V or
nominal 220 V circuit, and has a grounding plug
that looks like the plug illustrated in sketch A in
Figure 3.1. A temporary adapter, which looks like
the adapter illustrated in sketches B and C, may be
used to connect this plug to a 2-pole receptacle as
shown in sketch B if a properly grounded outlet
is not available. e temporary adapter should
be used only until a properly grounded outlet can
be installed by a qualied electrician. e green
colored rigid ear, lug, and the like, extending from
the adapter must be connected to a permanent
ground such as a properly grounded outlet box
cover. Whenever the adapter is used, it must be held
in place by the metal screw.
Note: In Canada, the use of a temporary adapter is
not permitted by the Canadian Electric Code.
Grounding
Figure 3.1
