14221-1850-2000, Rev. A
10
Table 1-2: Calculated Minimum Safe Distance from LMR Antenna
(Based on Maximum Gain of Yagi/Log Periodic Antennas)
Mobile Command Center applications
TRANSMIT
FREQUENCY
RECOMMENDED MINIMUM LATERAL HUMAN BODY DISTANCE FROM TRANSMITTING
ANTENNA
U.S. CANADA
CONTROLLED
ENVIRONMENT
UNCONTROLLED
ENVIRONMENT
CONTROLLED
ENVIRONMENT
UNCONTROLLED
ENVIRONMENT
136 to 174 MHz 49 in (125 cm) 110 in (280 cm) 57 in (145 cm) 137 in (347 cm)
378 to 522 MHz 69 in (174 cm) 156 in (396 cm) 69 in (174 cm) 201 in (511 cm)
763 – 806 MHz 38 in (97 cm) 85 in (215 cm) 45 in (115 cm) 123 in (313 cm)
800 – 870 MHz 15 in (39 cm) 69 in (174 cm) 22 in (56 cm) 122 in (309 cm)
846 – 944 MHz 15 in (39 cm) 53 in (134 cm) 28 in (71 cm) 104 in (265 cm)
1.3.2 Approved Accessories
The radio has been tested and meets FCC RF guidelines when used with accessories supplied or designated
for use with it. Use of other accessories may not ensure compliance with the FCC’s RF exposure guidelines
and may violate FCC regulations. For a list of approved accessories, refer to the radio’s Installation Manual
and/or the Products and Services Catalog.
1.3.3 Contact Information
For additional information on RF exposure and other information, contact Harris using one of the contact
links listed in Section 10.
1.4 REGULATORY APPROVALS
1.4.1 Applicable Type Acceptance/Certification Numbers
FCC Type Acceptance:
XL-185M (14050-1100-11 Hardware): OWDTR-0160-E
XL-200M/XL-185M (14050-1100-01 Hardware): OWDTR-0161-E
Applicable FCC Rules: Part 15, Part 80, and Part 90
Industry Canada Certification:
XL-185M (14050-1100-11 Hardware): 3636B-0160
XL-200M/XL-185M (14050-1100-01 Hardware): 3636B-0161
Applicable Industry Canada Rules: RSS-247, RSS-119, ICES-003 Issue 6
