Harris XL Series User Manual

14221-1850-2000, Rev. A
58
5. ADVANCED OPERATIONS
5.1 VIEW/CHANGE PERSONALITIES
Personalities contain radio programming information such as frequencies, channels, stations, and talk
groups. Up to ten different personalities can be stored in the radio, but only one can be active at a time.
5.1.1 View Personalities
1. Press the Menu button.
2. Navigate to the UTILITY menu.
3. Scroll up or down to highlight PROGRAM and press the Group/Channel Select Knob.
4. An arrow indicates the currently active personality. Press the OPTIONS soft key.
5. Select VIEW PLAN INFO to view.
6. The radio displays the plan’s filename. Personality information appears if populated using RPM2.

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
