Harris XL Series User Manual

14221-1850-2000, Rev. A
78
5.14 RADIO STATUS
The status feature allows the radio user to send a status condition to the site without making a voice call.
There can be up to ten (10) status conditions programmed into the radio. For each status defined, there is
an ID and an alphanumeric name. The ID is sent to the site and the alphanumeric name appears on the radio
display when the ID corresponds with the information programmed at the site.
A button on the control head or KMM can be programmed to send a radio status (see
Section 6.4).
To send a radio status:
1. Press the Menu button.
2. Navigate to the MESSAGES menu.
3. Highlight RADIO STATUS and press the Group/Channel Select Knob.
4. Scroll up or down to highlight the desired message and press the Group/Channel Select Knob.
5.15 RADIO MESSAGE
The message feature is used to send a message to the site without making a voice call. There can be up to
ten (10) messages programmed into the radio. For each message defined, there is an ID and an alphanumeric
name. The ID is sent to the site and the alphanumeric name appears on the radio display when the ID
corresponds with the information programmed at the site.
A button on the control head or KMM can be programmed to send a radio message (see
Section 6.4).
To send a radio message:
1. Press the Menu button.
2. Navigate to the MESSAGES menu.
NOTE
NOTE

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
