Harris XL Series User Manual

14221-1850-2000, Rev. A
67
5.8 GPS SETTINGS
The GPS SETTINGS menu item only appears if enabled using RPM2 and the feature
is installed.
To access GPS settings:
1. Press the Menu button.
2. Navigate to the UTILITY menu.
3. Highlight GPS and press the Group/Channel Select Knob.
4. Scroll up or down to highlight desired menu selections and press the Group/Channel Select Knob to
change settings:
• GPS - Enable or disable internal GPS.
• POSITION INFO - See Section 5.9.
• LINEAR UNITS - Set unit of measurement of displayed linear units: STATUTE, METRIC, or
NAUTICAL.
• ANGULAR UNITS - Set unit of measurement of displayed angular units: CARDINAL,
DEGREES, or MILS.
• POSITION FORMAT - Set format of displayed position information: Latitude/Longitude
Decimal Degrees (LAT LONG DD), Latitude/Longitude Degrees Minutes Seconds (LAT/LONG
DMS), LAT/LONG DM, Military Grid Reference System (MGRS), or Universal Transverse
Mercator (UTM).
• SA OVER NETWORK - Allows the radio user to send GPS data to a Harris-supplied PC client.
5. Press the BACK soft key to exit the menu.
NOTE

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
