6.4 PROGRAMMABLE BUTTONS
When a KMM is used with the radio, the functions programmed to the one-dot, two-dot,
and three-dot buttons are the same for the KMM and Control Head.
Press the down navigation button while on the main display to view the functions assigned to the
programmable buttons. The programmable buttons are programmed using RPM2. A delay of 0 to 10
seconds can be defined using RPM2 for the programmable buttons. Refer to Figure 4-1 and Figure 4-2 for
the location of the programmable buttons on the XL Control Head and KMM. Table 6-2 lists and describes
the functions that can be programmed to the XL Control Head and KMM buttons:
Table 6-2: Programmable Button Options
No Function
Accent Backlight
Allows the radio user to change the backlight for the buttons on the XL mobile control
head.
User Login
Allows the user to enter a User ID and or Password to log into the P25 system (see
Section 4.4.1).
Adjust Squelch Allows the user to adjust the analog squelch level.
Bluetooth
Enable/Disable
Enable/disable Bluetooth. See Section 5.10 for more information.
Channel Guard Override Allows the user to pick a different Channel Guard setting for the current channel.
Direct System/Zone
Entry
Allows the user to select system/zone.
Drop Call Drop or terminate any group call that the radio receives.
Editable Preset
When this button is pressed and held for four (4) seconds, the radio saves the
currently selected System/group or Zone/channel to this button.
When this button is pressed and released in less than four (4) seconds, the radio
changes to the user-saved System/group or Zone/channel if already saved by the
user.
If System/group or Zone/channel is not configured for this button, when user defined
preset button is pressed and released in less than four (4) seconds, the radio displays
“Preset Empty.”
Fixed Preset
When this button is pressed and released, the radio changes to the System/Group or
Zone/Channel specified in RPM2.
Front Backlight Mode Toggles front display’s backlight On/Off/Momentary/Momentary (Off).
Home Goes to home channel.
Initiate Individual Call Initiate an Individual Call (See Section 4.13).
Initiate Phone Call Initiate a phone call (see Section 4.20).
Initiate OTAR Initiate OTAR (see Section 5.19.8).
Lock Keypad Locks the programmable function keys and navigation keys.
Monitor Toggle Toggles Monitor On/Off.
Monitor/Clear
Temporarily turn off selected squelch to monitor for traffic that may not normally break
squelch. Also, press this button followed by the emergency button to clear an
emergency.
Numeric Channel Entry Allows the radio user to manually enter the group/channel number (see Section 4.11).
Nuisance Delete Performs a Nuisance Delete. See Section 4.25 for more information.
Scan Enable/Disable Enable/disable scan.
To Next Page
