Harris XL Series User Manual

14221-1850-2000, Rev. A
42
4.13.2 Receiving an Individual Call
1. When receiving an Individual Call, the radio displays the calling radio’s name or Unit ID. The radio
will also display “PRESS  TO END.”
2. Press PTT to respond or the right navigation button to END/REJECT the call. How long the radio
remains in the Individual Call mode with no activity is programmable.
3. The radio rings and indicates a missed call if you do not respond. The ring sounds until you press PTT,
view the missed call menu using the up navigation key, change channel/group/system, or power cycle
the radio.
4. The radio can store up to ten (10) missed call entries. Select one of these entries to call the unit back.
or press the DISMISS soft key to clear the entry.

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
