Harris XL Series User Manual

14221-1850-2000, Rev. A
41
4. Scroll up or down to highlight the unit to call and press the Group/Channel Selection Knob.
Or
Select KEYPAD to enter the Unit ID. Use the KMM or navigation keys and the Group/Channel Select
Knob to enter the ID and press ENTER.
The soft keypad is not displayed when a KMM is connected.
5. Press PTT to make the call. When transmitting an Individual Call, the radio displays the called radio’s
name or Unit ID. If the radio is programmed for Acknowledged Individual Call, the radio displays
“CALL QUEUED” until the callee answers or rejects the call.
6. After the callee answers, press PTT to respond.
7. Press the right navigation arrow to end the call.
How long the radio remains in Individual Call mode with no activity is programmable.
NOTE

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
