Harris XL Series User Manual

14221-1850-2000, Rev. A
68
5.9 POSITION INFO
The Position Info screen displays the radio user’s location information. GPS must be enabled in the GPS
Settings (see Section 5.8).
To display position info:
1. Press the Menu button.
2. Navigate to the UTILITY menu.
3. Highlight POSITION INFO and press the Group/Channel Select Knob.
4. Press the up or down navigation buttons to scroll through available location information.
5.10 BLUETOOTH
The BLUETOOTH menu item only appears if enabled using RPM2 and if the feature is
installed.
5.10.1 Enable Bluetooth
To enable Bluetooth:
1. Press the Menu button.
2. Navigate to the UTILITY menu.
3. Highlight BLUETOOTH and press the Group/Channel Select Knob.
NOTE

Harris XL Series Specifications

General

Battery Type	Lithium-ion
GPS	Yes
Bluetooth	Yes
Dimensions	5.5 x 2.5 x 1.5 inches
Operating Temperature	-30°C to 60°C
Operating Modes	Analog
Encryption	AES
Modulation	FM
