Operation via fieldbus
98
a4643-1.0 HBM: public ClipX
Gross 3 Gross signal.
Net 4 Net signal.
Minimum 5 Peak value minimum.
Maximum 6 Peak value maximum.
Peak-to-peak 7 Peak value peak-to-peak.
Captured value 1 8 Captured value 1.
Captured value 2 9 Captured value 2.
ClipX bus value 1 10 Value on the device's ClipX bus with address 1.
ClipX bus value 2 11 Value on the device's ClipX bus with address 2.
ClipX bus value 3 12 Value on the device's ClipX bus with address 3.
ClipX bus value 4 13 Value on the device's ClipX bus with address 4.
ClipX bus value 5 14 Value on the device's ClipX bus with address 5.
ClipX bus value 6 15 Value on the device's ClipX bus with address 6.
Calculated value 1 21 Value of calculated channel 1.
Calculated value 2 22 Value of calculated channel 2.
Calculated value 3 23 Value of calculated channel 3.
Calculated value 4 24 Value of calculated channel 4.
Calculated value 5 25 Value of calculated channel 5.
Calculated value 6 26 Value of calculated channel 6.
External Eth. value 1 27 Value 1 transmitted via the Ethernet API.
External Eth. value 2 28 Value 2 transmitted via the Ethernet API.
External FB value 1 29 Value 1 transmitted via the fieldbus.
External FB value 2 30 Value 2 transmitted via the fieldbus.
Analog output 31 Value of the analog output in V or mA.
Explanation Bit Explanation
