8.4 Data transfer from the ClipX to the controller
See also Data types used by the ClipX.
The following table sets out the data and the speed at which the data are
updated by the ClipX in the event of a change. The speed (cycle in ms) is not
synchronized with the fieldbus, or with PROFINET IRT or EtherCAT Distributed
Clocks.
Expla-
nation
Format
Cycle in
ms
Explanation
ADC value
REAL 0.052
Output signal of the A/D converter in digits.
Electrical
value (field
value)
Input signal in the unit of the measured vari-
able, e.g. in mV/V.
Gross value Gross signal.
Net value Net signal.
Minimum
value
Peak value minimum.
Maximum
value
Peak value maximum.
Peak-to-peak
value
Peak value peak-to-peak.
Captured
value 1
REAL 1
Captured value 1.
Captured
value 2
Captured value 2.
ClipX bus
value 1 … 6
REAL 1
Value on the device's ClipX bus with address
1 … 6.
Calculated
value 1 … 6
REAL 1
Value of calculation channel 1 … 6.
Limit values
1 … 4
REAL
Event-
controlled
Value of the respective limit value 1 … 4.
