Operation via fieldbus
78
a4643-1.0 HBM: public ClipX
1)
The time is dependent on the update rate of the source signal.
The following table shows the byte assignment of the object value when
accessing the object dictionary.
8.5 Settings for the fieldbuses
The following sections set out the minimum settings you need to make in your
web browser for the respective fieldbuses.
See also
Connecting via Ethernet, Setting the ClipX using a web browser.
8.5.1 Settings for PROFINET
In your browser, specify the device name (Name of station). The name must be
unique within the network. It may also be easier to specify the IP address and
subnet mask (Netmask) there. Click on
APPLY to apply the settings. But you
Reply when
writing to the
object dictio-
nary
UINT
(Index)
1
Reply to the write request: The object has
been successfully written to if Index and
Subindex are identical to the request and the
error byte is zero.
USINT
(Sub-
index)
USINT
(Error)
Bit 31 … 24 Bit 23 … 16 Bit 15 … 8 Bit 7 … 0
Data object types UDINT, DINT, REAL
Not used Data object types INT, UINT
Not used Data object types
SINT, USINT
Expla-
nation
Format
Cycle in
ms
Explanation
