6.6 Connecting transducers
The signals of the connected sensor or signal are digitized by the ClipX at
19.2kHz. You can view various signal processing data values in your browser:
• the field value, i.e. the input signal,
• the ADC value, i.e. the signal of the A/D converter in digits,
• the filtered ADC value, i.e. the signal of the A/D converter based on your
selected filter, also in digits,
• the gross signal, i.e. the signal after zero balancing and scaling,
• the net signal, i.e. the signal after taring.
The taring level is located in the signal path after the gross signal. Normally the
taring function is only required for weighing applications, such as to record the
content and total weight of a container.
6.6.1 Strain gage full and half bridge, voltage-fed piezo-resistive sensors
When connecting transducers in a 6-wire configuration, you can also use zero-
wire TEDS instead of the 1-wire TEDS connection. In this case the TEDS
module is looped into the sense lines.
See also Available connections and LEDs
, Shielding and grounding design.
Important: Refer to the information on the connection clamps (Avail-
able connections and LEDs) and cable shielding (Shielding and
grounding design).
The use of TEDS is not yet supported by the current firmware version.
It will be in one of the future versions however.
