5 Mounting
The ClipX is designed for mounting on a support rail (35mm DIN rail to DIN
EN 60715). You can choose different mounting methods if you want though. The
support rail on which you mount the ClipX may be 8.5 or 16mm deep.
5.1 Mounting on a support rail
Fig. 3: Mounting on a support rail
1. Hang the ClipX from the top edge of the support rail.
2. Push the ClipX onto the support rail in the direction of the arrow as shown in
the picture.
The clip at the bottom secures the ClipX by a spring.
Important: You must ground the support rail.
