HBM ClipX - Current Drain (4 … 20 Ma)

Electrical connections, LEDs
ClipX
a4643-1.0 HBM: public 45
6.6.7 Current drain (4 … 20mA)
See also Available connections and LEDs
.
Fig. 21: Plug terminals X2 and X4, pin assignment for current drain
The use of TEDS is not yet supported by the current firmware version.
It will be in one of the future versions however.
Digital In 2
DI2
DI1
DO2
DO1
Digital In 1
Digital Out 2
Digital Out 1
Supply 0 V
0V
24V
Supply 10 … 30 V
AI
Plug terminal X4, transducer connection
Plug terminal X2
1-Wire-TEDS
TEDS
Pt100
1
2
1
2'
3
3'
2
S
4
Measurement signal +
Sense lead -
Bridge excitation voltage +
Sense lead +
Bridge excitation voltage -
Cable shield
Measurement signal -
I
U
Analog GND
Current input
Voltage input
GND
Sensor
