HBM ClipX - DPV1 Objects

Operation via fieldbus
ClipX
a4643-1.0 HBM: public 81
vant. There are, however, PROFIBUS configuration tools that only send DPV1
requests when there is actually a module in the scanned slot. In this case you
must fill up the empty slots.
DPV1 objects
R/W: RO = read only, RW = read and write, WO = write only. UINT = unsigned
integer.
The ClipX object directory index and subindex is stated for information purposes
only.
CiA404-compliant objects are located in slot 4.
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
1 1 4 FLOAT RO ADC FLOAT unfil-
tered
0x44f0 1
1 2 4 FLOAT RO ADC FLOAT filtered 0x44f0 2
1 3 4 FLOAT RO Field value (electr.
value)
0x44f0 3
1 4 4 FLOAT RO Gross value 0x44f0 4
1 5 4 FLOAT RO Net value 0x44f0 5
1 6 4 FLOAT RW Min value 0x44f0 6
1 7 4 FLOAT RW Max value 0x44f0 7
1 8 4 FLOAT RO Peak-to-peak value 0x44f0 8
1 9 4 FLOAT RO Captured value 1 0x44f0 9
1 10 4 FLOAT RO Captured value 2 0x44f0 10
1 11 4 FLOAT RO External ClipX 1
value
0x44f0 11
