Operation via fieldbus
82
a4643-1.0 HBM: public ClipX
1 12 4 FLOAT RO External ClipX 2
value
0x44f0 12
1 13 4 FLOAT RO External ClipX 3
value
0x44f0 13
1 14 4 FLOAT RO External ClipX 4
value
0x44f0 14
1 15 4 FLOAT RO External ClipX 5
value
0x44f0 15
1 16 4 FLOAT RO External ClipX 6
value
0x44f0 16
1 22 4 FLOAT RO Calculated channel 1
value
0x44f0 22
1 23 4 FLOAT RO Calculated channel 2
value
0x44f0 23
1 24 4 FLOAT RO Calculated channel 3
value
0x44f0 24
1 25 4 FLOAT RO Calculated channel 4
value
0x44f0 25
1 26 4 FLOAT RO Calculated channel 5
value
0x44f0 26
1 27 4 FLOAT RO Calculated channel 6
value
0x44f0 27
1 28 4 FLOAT RW Ethernet API value 1 0x44f0 28
1 29 4 FLOAT RW Ethernet API value 2 0x44f0 29
1 30 4 FLOAT RW Fieldbus value 1 0x44f0 30
1 31 4 FLOAT RW Fieldbus value 2 0x44f0 31
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
