HBM ClipX - Page 85

Operation via fieldbus
ClipX
a4643-1.0 HBM: public 83
1 32 4 FLOAT RO Analog output elec-
trical value
0x44f0 32
1 99 4 UINT32 RO All measval statuses 0x44f4 1
2 1 4 FLOAT RW Discharge rate Min /
second
0x4021 1
2 2 4 FLOAT RW Discharge rate Max /
second
0x4021 2
2 3 4 FLOAT RO Discharge rate Min
step
0x4021 3
2 4 4 FLOAT RO Discharge rate Max
step
0x4021 4
2 5 4 UINT32 RO Discharge Min
divider
0x4021 5
2 6 4 UINT32 RO Discharge Max
divider
0x4021 6
2 7 1 UINT8 RW Signal source
Min/Max
0x4020 1
2 11 4 UINT32 RW Clear Min/Max flags
mask low
0x4022 1
2 12 4 UINT32 RW Clear Min/Max flags
mask high
0x4023 1
2 13 1 UINT8 RW Clear Min/Max flags
invert
0x4024 1
2 14 4 UINT32 RW Hold Min/Max flags
mask low
0x4025 1
2 15 4 UINT32 RW Hold Min/Max flags
mask high
0x4026 1
DPV1
No of
bytes
Data
type
R/W Description
ClipX object
directory
Slot Index Index
Sub-
index
